Low-Voltage Main Distribution Cabinet

Standard: GB/T 7251.12 & IEC 61439-2
Horizontal busbar current: Up to 6300A
Vertical busbar current: 1600A – 4000A
Short time withstand: 100kA/1s

Send Inquiry

What Is This Product? – It Is the Main Control Point for Low Voltage Power

A Low-Voltage Main Distribution Cabinet usually sits next to the transformer on the low voltage side.
It takes the 400V or 690V power from the transformer and splits it into many branch circuits.
It also protects the lines against overload, short circuit, and leakage.
This product follows GB/T 7251.12 and IEC 61439-2.
The horizontal busbar max current is 6300A.
The vertical busbar current is 1600A to 4000A.
Short time withstand current (Icw) reaches 100kA for 1 second.
The cabinet can have drawer units or fixed units, or a mix of both, to fit different loads.
Large customers like China Railway and China Railway Construction use this Low-Voltage Main Distribution Cabinet to manage all the power in their factories.

FAQ

Can I mix drawer and fixed units in one cabinet?

Yes, we can design it both ways to match your needs.
Drawer units are interchangeable for the same size.

What Materials and Processes Do We Use? – We Use a Strong Frame and Busbars That Cool Well

The cabinet frame is made of C-type or nine-fold profiles.
The vertical posts are 2.5mm thick and can hold over 1000kg of static weight.
The doors use 2.0mm cold-rolled steel with polyurethane seals.
Protection rating is IP40 to IP54.
The main busbar uses rectangular or special-shaped copper bars, with many bars in parallel.
For very high current, you can add forced air cooling to lower the temperature rise.
All insulation parts are heat-resistant, with CTI≥600 and V0 flame retardant.
The cable compartment is ≥400mm deep for big cables.
Surface coating uses Swiss Gema spray guns for even thickness.
Salt spray test passes 720 hours without rust.
Our factory is 2,000 square meters with ISO9001 certification.

Parameter	Value
Standard	GB/T 7251.12 & IEC 61439-2
Horizontal busbar current	Up to 6300A
Vertical busbar current	1600A – 4000A
Short time withstand	100kA/1s
Frame post thickness	2.5mm
Protection rating	IP40 – IP54
Cable compartment depth	≥400mm
Salt spray test	720 hours

What Are the Core Advantages? – Drawer Units Are Swappable, and You Can Add Energy Management

First, it is modular and digital.
Drawer units can be swapped from the front.
For the same rating, they are 100% interchangeable.
Each drawer has three positions: connected, test, and separated.
All have mechanical indication and locking.
Each drawer can hold a molded case breaker, a thermal relay, a contactor, and more.
Current range is 16A to 630A.

Second, smart monitoring is built in.
You can install power monitoring terminals inside the cabinet.
They collect energy data from each circuit and send it to your energy management system (EMS) via Ethernet.

Third, it saves energy.
We include a reactive power compensation cabinet or a filter cabinet as standard.
After installation, your power factor can rise to above 0.95, saving you money on electricity.
This product has 3C and CE certification.
It is perfect for large malls, hospitals, and factories that need non-stop power.

FAQ

What is your company's experience?

Anhui Nanxian Electric Co., Ltd. has seven years in this industry.
We have supplied big state-owned enterprises with reliable products.
You can count on us for your Low-Voltage Main Distribution Cabinet.
